Pasar Wetan Revitalisation

Keeping a market alive while rebuilding its roof

Long daylit market hall with a steel roof structure
Year
2024
Location
Semarang, Central Java
Typology
Cultural
Area
2,100 m²
Role
Project Architect
Status
Completed

Overview

A working wet market re-roofed and re-planned in four phases, so that not one of its 180 traders lost a day of business.

The existing sheet roof leaked, trapped heat and turned the aisles dark. Closing the market to fix it was never an option — for most of the traders a week without a stall is a month without income.

The work was cut into four quadrants. Each was cleared, rebuilt and reoccupied in eleven weeks while traders moved into a temporary shed on the car park, then rotated back into their original pitch.

The new roof is a lightweight steel truss with clerestory glazing along every ridge and open ends for stack ventilation. Aisles were widened by 600mm, drainage channels were relaid to fall, and the fish section was moved to the windward edge.

Market aisle with produce stalls
Aisles widened by 600mm.
Clerestory glazing along a roof ridge
Light and heat leave by the same ridge.
Trader at a rebuilt stall
Traders rotated back to their original pitch.
Roof structure seen from below
Lightweight truss on the existing footings.

Credits

Client
Dinas Perdagangan Semarang
Traders
Paguyuban Pedagang Pasar Wetan
Contractor
PT Bangun Sejahtera
Photography
Placeholder — Unsplash
